RCBOs
RCBOs provide combined overload, short-circuit and residual current protection for individual circuits. They are commonly used in consumer units and distribution boards where each circuit needs its own protective device instead of relying on shared RCD protection.
Browse Type A RCBOs, high immunity RCBOs, mini Type A RCBOs, 10kA RCBOs, EV RCBOs and three-phase RCBO options for domestic, commercial, EV, heat pump and inverter-fed circuits.
Quick answer: An RCBO combines MCB and RCD functions in one device, protecting a single circuit against overload, short circuit and earth leakage faults.
Read more about RCBO types and applications
- Type A RCBOs: for AC and pulsating DC residual current protection
- High immunity RCBOs: useful where nuisance tripping is a concern
- Mini RCBOs: compact options for tighter consumer units
- 10kA RCBOs: higher breaking capacity options for suitable installations
- EV and heat pump circuits: choose protection based on the equipment manufacturer’s requirements
Type A RCBO – 16A C Curve, 30mA
£14.50
The WRT116C-030 is a 16A C Curve Type A RCBO combining overcurrent and 30mA residual current protection in one slimline device. With switched live and neutral disconnection, bi-directional wiring for solar PV and inverter-fed systems, and high immunity electronics to minimise nuisance trips, it is...
Type A RCBO – 20A B Curve, 30mA
£14.50
The WRT120B-030 is a 20A B Curve Type A RCBO that combines overcurrent and residual current protection in a single compact device. Featuring switched live and neutral disconnection for full isolation, bi-directional wiring for solar and EV applications, and a high immunity design to minimise...
Type A RCBO – 16A B Curve, 30mA
£14.50
The WRT116B-030 is a 16A B Curve Type A RCBO combining residual current and overcurrent protection in one compact device. It features switched live and neutral disconnection for full isolation, a high immunity design to reduce nuisance tripping, and bi-directional wiring for use in solar...
High Immunity Type A Mini RCBO – 40A B Curve (WRB140B-030)
£11.85
The WRB140B-030 High Immunity Type A Mini RCBO is a 40A B Curve protective device for residential and commercial circuits requiring higher current handling. At just 18mm wide, it combines overload, short-circuit, and residual current protection in a single compact module. With 30mA Type A...
High Immunity Type A Mini RCBO – 32A C Curve (WRB132C-030)
£11.85
The WRB132C-030 High Immunity Type A Mini RCBO is a 32A C Curve protective device engineered for circuits with higher inrush demands. Its slim 18mm design combines overload, short-circuit, and residual current protection in one module. With 30mA Type A sensitivity and a high-immunity build,...
What Types of RCBO Are Available?
Different RCBO types are specified depending on the electrical characteristics of the installation and the connected equipment.
Type A RCBO
Type A RCBOs detect AC and pulsating DC earth leakage currents. They are the standard choice for most modern UK domestic installations and comply with 18th Edition requirements.
Type B / DC-Sensitive Protection
Some EV, solar and inverter-fed circuits may require protection capable of detecting smooth DC residual current. Where this is specified, check whether the installation requires a dedicated Type B RCD, a suitable RCBO arrangement, or another manufacturer-approved protective device.
High Immunity RCBO
High Immunity RCBOs are designed to reduce nuisance tripping in electrically noisy environments. They are commonly used in circuits supplying IT equipment, refrigeration systems and commercial installations.
Single Phase vs Three Phase RCBO
Single phase RCBOs are used in standard domestic consumer units. Three phase RCBOs are required in commercial or industrial installations where balanced multi-phase protection is needed.
When Should You Use an RCBO?
RCBOs are recommended when independent circuit protection is required. Unlike split-load RCD boards, each circuit is protected individually, meaning one fault does not disconnect the entire installation.
- Domestic rewires and new builds
- EV charger circuits
- Heat pump supplies
- Commercial distribution boards
- Circuits where discrimination is required
RCBO Standards & Compliance
RCBOs are typically manufactured to BS EN 61009. Always select the correct device type, current rating, breaking capacity and curve for the circuit design, connected equipment and consumer unit compatibility.
