WME 12 Module Surge Protected Metal Enclosure – 100A Main Switch + SPD (WME12/SP)
£65.75
ex VAT
£78.90 inc VAT
SKU: WME12/SP
The WME12/SP is a 12 module surge protected metal enclosure fitted with a 100A main switch and an integrated Type 2 Surge Protection Device (SPD). Built for EV charger supplies, domestic distribution upgrades, and renewable systems, it provides safe isolation and reliable surge defence in a durable steel housing. With...
Read full descriptionAccepted payment methods
Description
The WME12/SP is a 12 module surge protected metal enclosure fitted with a 100A main switch and an integrated Type 2 Surge Protection Device (SPD). Built for EV charger supplies, domestic distribution upgrades, and renewable systems, it provides safe isolation and reliable surge defence in a durable steel housing.
With 9 usable ways, the WME12/SP offers more space than smaller boards, making it ideal for EV installs with multiple outgoing circuits, hybrid heat pump systems, or PV inverter connections. Each enclosure is built from 1.2mm non-combustible steel, powder-coated in white, and designed for fast, tidy installs with raised DIN rail, knockouts, and ample wiring room.
Installer Tip: The 12 module version is a sweet spot for EV or renewable installs that need extra ways beyond a simple charger supply — giving flexibility without the size of larger boards.
Key Features
- 100A main switch isolator – full circuit isolation
- Type 2 SPD included – Amendment 2 compliant surge protection
- 12 module enclosure – 9 usable outgoing ways
- 1.2mm steel body, powder-coated white
- Neutral & earth bars on both sides, fully shrouded terminals
- Removable gland plate for straightforward cable entry
- Complies with BS EN 61439-3 & BS 7671:2018 A2
Compare WME Surge Protected Enclosure Variants
| Model | Modules | Usable Ways | Protection |
|---|---|---|---|
| WME10/SP | 10 | 7 | 100A Main Switch + SPD |
| WME12/SP (This Product) | 12 | 9 | 100A Main Switch + SPD |
| WME14/SP | 14 | 11 | 100A Main Switch + SPD |
| WME16/SP | 16 | 13 | 100A Main Switch + SPD |
| WME18/SP | 18 | 15 | 100A Main Switch + SPD |
Technical specs
- Enclosure: 12 module steel housing, IP40
- Main Switch: 100A isolator
- Surge Protection: Type 2 SPD, pre-fitted
- Usable Ways: 9
- Material: 1.2mm non-combustible steel, white powder coat
- Operating Voltage: 230V AC, 50Hz
- Standards: BS EN 61439-3, BS 7671:2018 A2
Installation notes
This enclosure is supplied fully assembled with main switch and SPD fitted. Final wiring and certification must be carried out by a qualified electrician.
- Delivered pre-built – no extra internal wiring needed
- Knockouts and gland plate provided for easy entry
- Ensure 12 module (9 usable ways) meets load requirements
- Indoor installation only (IP40)
FAQs
When should I use the 12 module enclosure?
It’s a strong fit for EV installs with multiple outgoing circuits or hybrid renewable setups where more space is needed compared with a 6, 8, or 10 module board.
Does this include surge protection?
Yes. It includes a factory-fitted Type 2 SPD, meeting Amendment 2 compliance.
Is it outdoor rated?
No. This model is IP40 steel, intended for indoor use. For weatherproof boards, see our IP65 EV units.
How long for delivery?
Units are built to order. Allow 3 working days for build time, with free UK mainland next-day delivery once dispatched.
