WME 18 Module Surge Protected Metal Enclosure – 100A Main Switch + SPD (WME18/SP)
£61.85
ex VAT
£74.22 inc VAT
SKU: WME18/SP
Forward orders accepted — ask us for the current lead time
Ask us about availability
Currently unavailable
The WME18/SP is an 18 module surge protected metal enclosure fitted with a 100A main switch and integrated Type 2 Surge Protection Device (SPD). It’s built for EV-ready installs, domestic distribution boards, and renewable systems where extra capacity is needed for multiple outgoing circuits. With 15 usable ways, the WME18/SP...
Read full descriptionAccepted payment methods
Description
The WME18/SP is an 18 module surge protected metal enclosure fitted with a 100A main switch and integrated Type 2 Surge Protection Device (SPD). It’s built for EV-ready installs, domestic distribution boards, and renewable systems where extra capacity is needed for multiple outgoing circuits.
With 15 usable ways, the WME18/SP provides ample space for multi-charger EV hubs, heat pump circuits, or PV inverter connections. The enclosure is made from 1.2mm non-combustible steel with a powder-coated white finish, featuring raised DIN rail, generous wiring room, and multiple knockouts to simplify installation.
Installer Tip: The 18 module board is ideal when a 16 module leaves you short on space. Choose this size if you expect future circuit expansion alongside EV and renewable installs.
Key Features
- 100A main switch isolator – full isolation for safe maintenance
- Type 2 SPD included – transient overvoltage protection, Amendment 2 compliant
- 18 module enclosure – 15 usable outgoing ways
- 1.2mm steel body, powder-coated white
- Neutral & earth bars both sides, fully shrouded terminals
- Removable gland plate and multiple knockouts
- Complies with BS EN 61439-3 & BS 7671:2018 A2
Compare WME Surge Protected Enclosure Variants
| Model | Modules | Usable Ways | Protection |
|---|---|---|---|
| WME16/SP | 16 | 13 | 100A Main Switch + SPD |
| WME18/SP (This Product) | 18 | 15 | 100A Main Switch + SPD |
| WME22/SP | 22 | 19 | 100A Main Switch + SPD |
| WME28/SP | 28 | 24 | 100A Main Switch + SPD |
Technical specs
- Enclosure: 18 module steel housing, IP40
- Main Switch: 100A isolator
- Surge Protection: Type 2 SPD, pre-fitted
- Usable Ways: 15
- Material: 1.2mm non-combustible steel, white powder coat
- Operating Voltage: 230V AC, 50Hz
- Standards: BS EN 61439-3, BS 7671:2018 A2
Installation notes
This enclosure is supplied fully built with main switch and SPD fitted. Final wiring and certification must be completed by a qualified electrician.
- Pre-assembled – no additional internal wiring required
- Knockouts and removable gland plate for flexible entry
- Ensure 18 module (15 usable ways) suits your design requirements
- Indoor installation only (IP40 steel housing)
FAQs
When should I choose the 18 module version?
Select this size when you need extra capacity for EV hubs, heat pump systems, or future expansion beyond a 16 module board.
Does it include surge protection?
Yes, it comes pre-fitted with a Type 2 SPD to protect circuits from transient overvoltages and meet Amendment 2 compliance.
Can I install this outdoors?
No, this is an IP40 indoor-rated steel board. For weatherproof solutions, see our IP65 EV boards.
What’s the delivery lead time?
All WME units are built to order. Allow 3 working days for build time, with free next-day UK mainland delivery once dispatched.
