WME 36 Module Surge Protected Metal Enclosure – 100A Main Switch + SPD (WME36/SP)
18th Ed. Compliant
2-Year Warranty
UK Stock
Free Delivery £30+
Secure Payments With
The WME36/SP is the largest model in the WME range — a 36 module surge protected metal enclosure with a 100A main switch and integrated Type 2 Surge Protection Device (SPD). Designed for large EV hubs, renewable-heavy systems, and commercial distribution boards, it delivers safe isolation and full surge compliance...
The WME36/SP is the largest model in the WME range — a 36 module surge protected metal enclosure with a 100A main switch and integrated Type 2 Surge Protection Device (SPD). Designed for large EV hubs, renewable-heavy systems, and commercial distribution boards, it delivers safe isolation and full surge compliance in a robust steel housing.
With 32 usable ways, the WME36/SP is built for multi-charger EV installations, commercial premises, or complex renewable setups where maximum circuit capacity is essential. Constructed from 1.2mm non-combustible steel with a white powder-coated finish, it’s designed for installers with raised DIN rail, knockouts, removable gland plate, and a generous wiring area for neat and efficient connections.
Installer Tip: Opt for the 36 module version when you need maximum outgoing capacity. Perfect for commercial EV charging bays, multi-renewable setups, or future-proofing large residential installs.
Key Features
- 100A main switch isolator – full circuit isolation
- Factory-fitted Type 2 SPD – transient surge protection, Amendment 2 compliant
- 36 module enclosure – 32 usable outgoing ways
- 1.2mm steel body, powder-coated white
- Neutral & earth bars fitted both sides, shrouded terminals
- Removable gland plate and multiple knockouts
- Complies with BS EN 61439-3 & BS 7671:2018 A2
Compare WME Surge Protected Enclosure Variants
| Model | Modules | Usable Ways | Protection |
|---|---|---|---|
| WME28/SP | 28 | 24 | 100A Main Switch + SPD |
| WME36/SP (This Product) | 36 | 32 | 100A Main Switch + SPD |
Who is the WME36/SP designed for?
It’s intended for large-scale installs such as EV hubs, commercial premises, or complex renewable systems needing maximum outgoing capacity.
Does this include surge protection?
Yes, it is supplied with a factory-fitted Type 2 SPD to protect circuits from transient overvoltages and meet Amendment 2 requirements.
Is it weatherproof?
No, this is an IP40 steel enclosure designed for indoor use. For outdoor EV installs, see our IP65-rated EV units.
How quickly can it be delivered?
All WME units are built to order within 3 working days. Once dispatched, free next-day UK mainland delivery applies to orders over £30.
- Enclosure: 36 module steel housing, IP40
- Main Switch: 100A isolator
- Surge Protection: Type 2 SPD, factory fitted
- Usable Ways: 32
- Material: 1.2mm non-combustible steel, white powder coat
- Operating Voltage: 230V AC, 50Hz
- Standards: BS EN 61439-3, BS 7671:2018 A2
This unit is supplied fully built with main switch and SPD fitted. A qualified electrician must complete final wiring and certification.
- Pre-assembled – no additional internal wiring required
- Knockouts and gland plate provided for adaptable cable entry
- Ensure 36 module (32 usable ways) suits circuit requirements
- Indoor installation only (IP40 rated steel housing)
