WRS4P63 – 63A 4 Pole AC Rotary Isolator, IP65
18th Ed. Compliant
2-Year Warranty
UK Stock
Free Delivery £30+
Secure Payments With
The WRS4P63 is a 63A 4 pole AC rotary isolator supplied in a rugged IP65-rated enclosure. Built for higher-demand circuits, it provides safe isolation of all live conductors (L1, L2, L3, N), making it ideal for commercial distribution boards, EV charging hubs, and industrial machinery. Its red/yellow rotary handle offers...
The WRS4P63 is a 63A 4 pole AC rotary isolator supplied in a rugged IP65-rated enclosure. Built for higher-demand circuits, it provides safe isolation of all live conductors (L1, L2, L3, N), making it ideal for commercial distribution boards, EV charging hubs, and industrial machinery.
Its red/yellow rotary handle offers clear ON/OFF indication and supports padlocking in the OFF position to prevent accidental reconnection during maintenance. Designed to comply with BS EN 60947-3 and BS 7671, this isolator is trusted in both indoor and outdoor installs.
Installer Tip: The 63A model is often used as the main isolator in light commercial boards or multi-point EV charging installs. For larger systems, step up to the 80A or 100A isolators.
Key Features
- 63A 4 Pole AC isolator – disconnects L1, L2, L3, and Neutral
- IP65 weatherproof housing – safe for outdoor or indoor installs
- Red/yellow handle – positive ON/OFF operation
- Padlock facility – lock OFF for safe maintenance
- Surface-mount with knockouts for gland entry
- Complies with BS EN 60947-3 and BS 7671
Compare AC Rotary Isolators
| Model | Rating | Poles | Enclosure |
|---|---|---|---|
| WRS4P40 | 40A | 4 Pole | IP65 |
| WRS4P63 (This Product) | 63A | 4 Pole | IP65 |
| WRS4P80 | 80A | 4 Pole | IP65 |
Where is the WRS4P63 commonly used?
It is often used as the main isolator in commercial distribution boards, EV hubs, and small industrial installs.
Does it isolate the neutral conductor?
Yes – all four poles (L1, L2, L3, N) are isolated simultaneously for safety.
Is this model weatherproof?
Yes – the IP65-rated enclosure allows outdoor use when fitted with sealed cable glands.
Does it support lock-off?
Yes – the handle can be padlocked in the OFF position for safe maintenance or emergency shutdown.
- Model: WRS4P63
- Type: 4 Pole AC Rotary Isolator
- Current Rating: 63A
- Rated Voltage: 230/400V AC
- Ingress Protection: IP65 enclosure
- Handle: Red/Yellow rotary, padlockable
- Operating Temperature: -25°C to +55°C
- Compliance: BS EN 60947-3, BS 7671
Supplied factory-assembled in an IP65 housing. Installation and testing must be completed by a qualified electrician.
- Mount securely on a flat wall or board
- Use IP-rated glands to maintain weatherproofing
- Confirm circuit suitability for 63A loads
- Lock handle in OFF position during service work
