The WKC216C is a 16 A 2 Pole 10 kA Miniature Circuit Breaker (MCB) designed for small-power and control circuits with moderate inrush currents. The C-curve tripping profile provides a short delay at start-up — ideal for motors, fans, heating controls, and automation panels where current peaks are common. Dual-pole...
The WKC216C is a 16 A 2 Pole 10 kA Miniature Circuit Breaker (MCB) designed for small-power and control circuits with moderate inrush currents. The C-curve tripping profile provides a short delay at start-up — ideal for motors, fans, heating controls, and automation panels where current peaks are common.
Dual-pole isolation ensures both live conductors are disconnected simultaneously, meeting BS EN 60898-1 standards for circuit protection and safety. Compact 36 mm body fits any 35 mm DIN rail enclosure including consumer units, modular enclosures, and commercial boards.
Installer Tip: Use a 16 A C-curve on small motor or control circuits where a B-curve may nuisance trip. For purely resistive loads, the B-curve version is suitable, while D-curves suit high inrush equipment.
Key Features
- 16 A rated – ideal for small motor and control applications
- 10 kA breaking capacity – suitable for commercial fault levels
- 2-pole design – isolates both live conductors together
- C-curve tripping – allows moderate inrush without unwanted trips
- Bi-directional terminals – can be wired from line or load end
- 36 mm width – compact DIN-rail footprint
- Fully compliant with IEC/EN 60898-1 and the 18th Edition Wiring Regulations
Compare 2 Pole 10 kA MCB Variants
| Model | Rating | Curve |
|---|---|---|
| WKC216B | 16 A | B Curve |
| WKC216C (This Product) | 16 A | C Curve |
| WKC216D | 16 A | D Curve |
What applications suit a 16 A C-curve MCB?
Used for small motors, control gear, and heating circuits where inrush current might cause a B-curve breaker to trip prematurely.
Does it disconnect both conductors?
Yes – 2-pole operation isolates both live lines simultaneously for safe maintenance.
Is it compliant with BS EN 60898-1?
Yes – tested to BS EN 60898-1 and fully compliant with the 18th Edition Wiring Regulations.
Can it be used for automation panels?
Yes – commonly installed in control or automation panels feeding motors or relays with brief inrush surges.
- Model: WKC216C
- Poles: 2
- Rated Current: 16 A
- Curve Type: C
- Breaking Capacity: 10 kA
- Operating Voltage: 230/400 V AC
- Mounting: 35 mm DIN rail (EN 60715)
- Width: 36 mm (2 modules)
- Standard: IEC/EN 60898-1
- Applications: Motors, control gear, fans, heating spurs
To be installed by a qualified electrician to BS 7671. Confirm correct cable size, circuit rating, and curve selection before fitting.
- Mount on 35 mm DIN rail (EN 60715)
- Torque terminals to 2.0–2.5 Nm
- Verify insulation resistance and polarity prior to energising
- Record and label protected circuits within the distribution schedule
