Surge Protection

Find surge protection devices and enclosed SPD units for electrical installations. Choose from compact Type 2 modules, main-switch assemblies with surge protection, Type 1+2 options and three-phase units. Start with the required SPD type, supply and enclosure format....

Read the collection guide

Surge Protection Devices & SPD Units

Find surge protection devices and enclosed SPD units for electrical installations. Choose from compact Type 2 modules, main-switch assemblies with surge protection, Type 1+2 options and three-phase units.

Start with the required SPD type, supply and enclosure format. WSPD140 is a standalone module; WEC440SP includes a main switch and enclosure. These are installation products for specification by an electrician, rather than plug-in extension-lead surge protectors.

Showing 31 to 40 of 40 items

Choose the SPD format that fits the installation

An SPD module and an enclosed surge-protection assembly solve different purchasing needs. Check what is included so you can order the device, housing and any required associated protection together.

Compare surge protection formats
ProductFormat and supplied equipmentSelection point
WSPD140Single-module, 1-pole Type 2 SPD; 20kA nominal / 40kA maximum discharge current.For a compatible SPD arrangement where a separate module is specified. It is not a complete enclosed unit.
WEC440SP100A double-pole main switch and Type 2 SPD in a compact plastic enclosure.Compare when the job needs an enclosed main-switch-and-SPD assembly.
WEC440SPT12100A main switch with Type 1+2 SPD in a compact plastic enclosure.Compare when the installation specification calls for Type 1+2 protection.
WMCUSP440CThree-phase Type 2 SPD with 40A C-curve MCB in a metal IP40 enclosure.An enclosed indoor three-phase option. This MCB version does not include an RCD or RCBO.

Four details to check before ordering

  • SPD type and application: Type 2 and Type 1+2 describe different protection classifications. Confirm the required arrangement from the installation design.
  • Supply and poles: match the device to the system voltage, phase arrangement and earthing system. A one-pole module is not automatically a complete single-phase protection solution.
  • Ratings: compare the SPD’s voltage and discharge-current data, plus the manufacturer’s requirements for associated protection. A 40kA surge rating is different from a 40A breaker rating.
  • Enclosure and assembly: check dimensions, ingress protection, device compatibility and the exact included components. An SPD does not provide residual-current protection.

Questions before ordering

Can I use an AC SPD on a solar DC string?

Do not substitute an AC SPD for the specified PV DC device. For DC-side assemblies, compare the solar combiner box range and check the DC voltage and string arrangement.

Does fitting an SPD guarantee protection from all lightning damage?

No. Surge protection is part of a coordinated installation design. Select and coordinate the devices for the installation; a product alone does not establish complete lightning protection or compliance.

Need a module or a complete enclosed unit?

Send the supply details, specified SPD type, proposed location and any existing board reference. Include the device code if replacing a component so compatibility can be checked. Contact Power & Data UK.
