Single Module 2 Pole RCBO 32A C Curve WRN32C-030
£18.65
ex VAT
£22.38 inc VAT
SKU: WRN32C-030
The WRN32C-030 is a 32A Type A RCBO with a C-curve tripping characteristic, supplied in a single-module, 2-pole format. Combining residual current (RCD) and overcurrent (MCB) protection, it safeguards circuits against AC and pulsating DC leakage. The built-in switched neutral ensures both live and neutral are disconnected on fault, keeping...
Read full descriptionAccepted payment methods
Description
The WRN32C-030 is a 32A Type A RCBO with a C-curve tripping characteristic, supplied in a single-module, 2-pole format. Combining residual current (RCD) and overcurrent (MCB) protection, it safeguards circuits against AC and pulsating DC leakage. The built-in switched neutral ensures both live and neutral are disconnected on fault, keeping installs compliant with BS 7671 (18th Edition) while improving site safety.
Installer Tip: A 32A C-curve RCBO is often specified for higher load appliance circuits, small submains, or equipment with high inrush currents, where a B-curve model could nuisance trip.
- 32A C-Curve RCBO: Suited to circuits with higher starting currents
- Type A protection: Trips on AC and pulsating DC residual currents
- Compact design: Single 18mm module width
- 2-pole switched neutral: Full isolation of live and neutral
- Minimises disruption: Only faulty circuits are disconnected
- BS 7671 compliant: Meets 18th Edition Amendment 2
Technical specs
| SKU | WRN32C-030 |
| Device Type | Type A RCBO |
| Current Rating | 32A |
| Curve | C Curve |
| Residual Current | 30mA |
| Poles | 2 Pole (Live + Neutral switched) |
| Module Width | 1 (18mm) |
| Dimensions | 18 × 82 × 77mm |
| Mounting | DIN rail |
| Standards | BS EN 61009-1, BS 7671 |
Installation notes
The WRN32C-030 installs into a single 18mm DIN rail slot and is compatible with most consumer units and distribution boards. Only a qualified electrician should carry out the final installation and testing.
- Standard DIN rail mounting with busbar compatibility
- Switched neutral ensures safe isolation during maintenance
- Compact 18mm design saves board space
- Includes test button for periodic inspection
FAQs
When should I use a 32A C-curve RCBO?
It’s suited to higher load appliance circuits, small submains, or equipment with higher inrush currents, such as pumps and compressors.
What’s the benefit of C-curve over B-curve?
C-curve devices handle higher inrush currents without nuisance tripping, whereas B-curve is used for standard domestic loads like sockets and lighting.
Does this device isolate neutral as well as live?
Yes — the switched neutral disconnects both conductors during a fault, improving site safety and compliance.
Will this fit into a standard consumer unit?
Yes. At only 18mm wide, it’s compatible with most UK DIN rail consumer units and distribution boards.
Is this fully compliant with UK regulations?
Yes. The WRN32C-030 is certified to BS EN 61009-1 and meets the 18th Edition Amendment 2 requirements.
When should I choose a B-curve instead of this C-curve?
If the circuit is a general domestic load with low inrush, such as lighting or sockets, the WRN32B-030 B Curve RCBO may be a better fit.
